1969 Dodge Charger Chassis Assembly Manual Reprint

Price: $24.00
  • Part #DB96969CRA11FLY1EAC
In stock now.
- +
This book is a reproduction of a manual originally used by workers on the factory assembly lines putting cars together. You'll see page after page of detailed illustrations of how each part fits others.  Use the part numbers and illustrations to help you verify original parts, to reassemble parts you are restoring, or to replace missing parts. You’ll find detailed parts illustrations and torque specs you haven’t seen anywhere else. This chassis manual includes transmission and clutch housing, clutch pedal and linkage, steering gear and linkage, shifter and linkage, steering column, suspension, brakes, brake pedals and linkage, brake lines, exhaust system, cruise control, and bumpers. This manual covers all 1969 Dodge Charger models, including 500, SE, Hemi, and R/T models. This 8.5 x 11 inch book has 86 pages and is in new condition. Like all assembly manuals, this is reproduced from a book made for use inside the factory, and never intended for the public. Therefore, the print (like the print in original assembly manuals) is occasionally light. We have made every effort to restore the book where possible. It includes a table of contents, index, and page title for each picture. Buy now to own this never before available book.
86
"1969 Dodge Chassis Assembly Manual Charger, 500, SE, and R/T"
Faxon Auto Literature
Sold Separately
This item is a reproduction
11.00 x 8.50 x 0.25 inches
DB96969CRA11FLY1EAC
Write a Review
This manual covers all 1969 Dodge Charger models, including 500, SE, and R/T models.
1969 Dodge Charger
1969 Dodge Charger 500
1969 Dodge Charger R/T
1969 Dodge Charger SE
1969 Dodge Charger
